By mudicipher Technology Tutorials 29 July 2022

WAYS TO IDENTIFY YOUR ENGINE

UNDERSTAND YOUR ENGINE PLATE, KNOW THE PARTS YOU NEED FOR YOUR ENGINE

Over the years Perkins has produced hundreds of different engines and each can have many different variants. So how do you know the exact specification of your engine? All the information you need about your engine is included in the serial number on your engine plate, which you can use to find the parts to fit on your engine.

WHERE CAN I FIND MY SERIAL NUMBER?

The engine serial number is on a metal plate attached to the block, typically found on the left-hand side of the engine. The position of the engine plate varies across different engine series. You can find the position of your plate using the table below.

engine number guide - engine plate position all.jpg

Engine type	Position	Engine type	Position
3.152	M	4.318	F
4.108	A	4.41	H
4.154/200 Series	B	6.247	C or F
4.165	B or G	6.354	D
4.203	J or N	V8.540	Q
4.212/4.248/900 Series	C	Peregrine/1300 Series	I or O
1106D including PK	R	V8.640	P
4.236	C or L	700/800 Series	K
Perama/100/400 Series	O	Phaser/1000/1100(A/B/C) Series	H or J
1104D	S	850 Series	D or R
1204E	S	1206E	R
1300 Series	T	1500/1600 Series	U

ENGINE SERIAL NUMBER COMPOSITION

The engine serial number is made up of several components. For example, a full engine serial number could be PJ12345U123456P.

The engine serial number is the complete number shown. This is made up of

the list number or build list, typically 2 to 4 letters followed by 4 or 5 numbers
a letter identifying the country
a series of numbers showing the build line, also called a serial number
a letter indicating the year of manufacture

1	2	3	4	5
PJ: is the engine family, in this case 1106D-E66TA	12345: is the engine build type number or engine order reference	U: is the country of manufacture, in this case UK	123456: is the unique engine number	P: is the year of manufacture

In the example above, engine is an 1106D-E66TA engine with a turbocharger

1106 is a 1.1L displacement per cylinder and six cylinders
D signifies that this engine is suitable for EU Stage III / U.S. EPA Tier 3 equivalent emissions standards
E identifies the engine has an electronic management system
66 confirms the engine has a total displacement of 6.6 litres
TA means the engine has a turbocharger and is air-to-air charge cooled

What do I need to enter in the search?

The minimum requirement to produce a result in the engine serial number search tool is the initial build list element, (2 to 4 letters followed by 4 or 5 numbers). Including the full entry of 15 or more digits will deliver the best results.

Guidelines

Do not enter spaces or symbols such as asterisks as the number will not be recognized.
Clean and check the plate carefully, as letters and numbers may look the same.
Capital letters are not required, the system recognizes both lower- and upper-case letters.

Typical examples of engines serial numbers

Small and medium engines PJ12345U123456P

1300 Series WGHF1234N13245U

1500 Series LGFF132N13245U

1600 Series XGDF134N12345W

2000 Series TGAF1234N12345A

4000 Series DGBF1324U12345B

Older engines SGA123456U1234Y
